เมนบอร์ด ASRock Rack W680D4U, LGA1700, Micro-ATX

► Micro-ATX 9.6″ x 9.6″ (244 mm x 244 mm)
► Support 12th/13th Gen Intel^® Core™ series processors
► Intel socket 1700
► Chipset W680
► 4 DIMM Slots, Supports DDR5 non-ECC/ECC UDIMM
► PCIe 4.0
► 2 x GbE LAN
► Remote management (IPMI)

฿18,500.00

แจ้งกับทางร้านก่อนชำระเงิน เพื่อตรวจสอบสถานะสินค้า และค่าจัดส่ง

Description
Specification

News & Update

Intel 600 Desktop Chipset Series แต่ละรุ่นแตกต่างกันอย่างไร?

July 4, 2023 No Comments

สวัสดีครับ พบกันอีกครั้งกับ PC Gallery ครับ วันนี้เราจะมาดูกันว่า Desktop Chipset ของ Intel 600 Series ในแต่ละรุ่นนั้นแตกต่างกันอย่างไรบ้าง? ก่อนอื่นเรามาทำความรู้จักกับ Intel 600 Series Desktop Chipsets แบบคร่าวๆ กันก่อนครับ Intel Chipsets ซีรี่ย์นี้ได้เปิดตัวครั้งแรกในปี 2021

Physical Status
Form factor	Micro-ATX
Dimensions	9.6″ x 9.6″ (244 mm x 244 mm)
Processor
CPU	12th/13th Gen Intel^® Core™ series processors
Socket	Single Socket LGA-1700
Chipset	Intel W680
System Memory
Support DIMM slot	4 DIMM slots
DIMM Type	DDR5 Non-ECC / ECC UDIMM
Memory Capacity	8GB, 16GB, 32GB up to 128GB
Frequency	4400MT/s (2DPC-1DIMM) / 4000MT/s (2DPC-2DIMM 1R) / 3600MT/s (2DPC-2DIMM 2R)
Network / IPMI
Integrated LAN	2 x RJ45 1GbE LAN ports with Inte i210 Controller
IPMI	1 x RJ45 1GbE LAN ports with Realtek RTL8211F PHY (Dedicated for IPMI)
Graphic
Controller	ASPEED AST2600 BMC
Expansion Slots
PCI-Express (PCI-E)	1 x PCIe 4.0 x16 (CPU) 1 x PCIe 4.0 x8 (CPU) 1 x PCIe 3.0 x1 (PCH)
M.2	1 x M.2 Interface: PCIe 3.0 x4 (CPU) Form Factor: 2280/2260/2240/2230 Key: M-Key
OCuLink	1 x OCuLink (PCIe 4.0 x4) (CPU) 1 x OCuLink (PCIe 4.0 x4 or 4 SATA 6Gb/s) (PCH) 2 x OCuLink (PCIe 4.0 x) (PCH)
Storage / Controller
PCH Built-in Storage	4 x SATA3 7-pin (6Gbps) port(s) 1 x OCuLink support RAID 0/1/5/10
Storage Controller	Intel W680 RAID support: 0/1/5/10
Input / Output
SATA	4 x SATA3 7-pin (6Gbps) port(s) 1 x OCuLink
LAN	1 x RJ45 1 GbE LAN ports
Dedicate LAN	1 x RJ45 dedicated for IPMI
USB	4 x USB 3.2 Gen1 port(s) (2 rear; 2 via header) 2 x USB 2.0 Port(s) (2 via header)
Video Output	1 x VGA port 1 x DVI-D port 1 x DP 1.4a port 1 x HDMI 2.0b port
Serial Port	1 x COM Port
DOM	–
TPM	1 x TPM Header
Supported OS
Microsoft Windows	Window 10 Pro (64 bit) Window 11 Pro (64 bit)
Linux	RedHat Enterprise Linux Server 8.5 (64bit) / 7.9 (64bit) CentOS 8.5 ( 64 bit) / 7.9 (64bit) SUSE SLES 15.2 (64 bit) / 12.5 (64bit)
Virtual Machine	VMWare^® ESXi 7.0 U3d VMWare^® ESXi 6.7.0 U3
Note	* Supports UEFI BOOT only.
