IceLake เซิร์ฟเวอร์ PowerRACK X12SPA-2108, XEON Gold 6326 16C/32T, 8Bays
- • Model: X12SPATF-2108-1300R-S16C32T
- • CPU: Intel Xeon Gold 6326, 2.90GHz, 24MB Cache, 185W, 16C/32T
- • CPU Cooler: Active Sink
- • RAM: Option
- • SSD: Option
- • VGA: ASPEED AST2500
- • RAID: RAID Controller, SAS, 9361-8i, 12Gb/s, SAS/SATA, 8port, 1GB
- • Drive: 8 x 3.5″/2.5″ Hot-swap SAS/SATA | 2 x 2.5″ rear Hot-swap
- • LAN: 2 GLAN with Intel® i210
- • IPMI: AST2600 BMC
- • CHASSIS: 2U Rackmount
- • PSU: 1300W Redundant
- • Warranty: 2-Year อะไหล่และค่าแรง, On-Shop Service
฿162,550.00
ราคาล่าสุดวันที่ July 4, 2026
ติดต่อสอบถามเกี่ยวกับสินค้าทางไลน์ ก่อนชำระเงิน
Please contact us via LINE for product inquiries before making a payment.
PowerRACK
X12SPA-2108
Rack Server ขนาด 2U ที่ขับเคลื่อนด้วย Intel Xeon Gold 6326 แบบ 16 Core / 32 Thread มาพร้อม RAID Controller SAS 9361-8i รองรับ RAID 0/1/5/10 เพิ่มความปลอดภัยของข้อมูล มีไดรฟ์แบบ Hot-swap 8 ช่องด้านหน้า และ 2 ช่องด้านหลัง พร้อม Power Supply แบบ Redundant 1300W เพื่อความต่อเนื่องในการทำงาน และรับประกัน 2 ปีเต็ม
Complete System
Supports 3rd Gen Intel® Xeon® Scalable processors, Intel® Xeon® W-3300 Processor
4 x M.2 Slots
13000W Redundant
4 PCI-E 4.0 x16,
3 PCI-E 4.0 x8 (in x16 slot)
8 x 3.5″/2.5″ Hot-swap SAS/SATA
Hot-swap fan
2 x USB3.0
| CPU | |
|---|---|
| Standard CPU | INTEL, 4189, XEON Gold 6326, 2.90GHz, 24MB Cache, 185W, 16C/32T |
| CPU Support | 3rd Gen Intel® Xeon® Scalable processors, Intel® Xeon® W-3300 Processor Single Socket LGA-4189 (Socket P+) supported, CPU TDP supports Up to 270W TDP |
| CPU Cooler | Active Sink |
| Memory | |
| Standard Memory | Option |
| Memory support | Total Slots : 16DIMM slots Max Memory Size : 4TB Max. Capacity per DIMM : 16GB, 32GB, 64GB, 128GB, 256GB DIMM Type : ECC-RDIMM, ECC-LRDIMM Supports DDR4 : 3200 MT/s |
| Network / IPMI | |
| Integrated LAN | 1 x Single LAN with Intel® Ethernet Controller I210-AT Ethernet controller 1 x Single LAN with Marvell AQC113 Ethernet controller |
| IPMI |
1 x ASPEED AST2600 BMC |
| Graphic | |
| Controller |
ASPEED AST2500 |
| Expansion Slots | |
| PCI-Express (PCI-E) | 4 x PCIe 4.0 x16 3 x PCIe 4.0 x8 (in x16 slot) |
| M.2 |
4 x M.2 PCI-E 4.0 x 4, M-Key, 2260/2280/22110 (Onboard) 8 x M.2 PCI-E 4.0 x4 , M-Key, 2242/2260/2280/22110 (PCIe Card M.2) |
| Storage / Controller | |
| Standard Storage | Option |
| Drive Bays | 8 x Front drive bays Hot-swap 2.5″/3.5″ 2 x Internal drive bays 2.5″ 2 x Rear drive bays Hot-swap 2.5″ |
| Storage | 4 x M.2 PCI-E 4.0 x 4, M-Key, 2260/2280/22110 (Onboard) 8 x M.2 PCI-E 4.0 x4 , M-Key, 2242/2260/2280/22110 (PCIe Card M.2) |
| Storage Controller | RAID Controller, SAS, 9361-8i, 12Gb/s, SAS/SATA, 8port, 1GB |
| SATA | 8 x SATA (6Gbps) ports RAID 0/1/5/10 |
| Cable |
N/A |
| Input / Output | |
| LAN | 1 x RJ45 1Gigabit Ethernet LAN port 1 x RJ45 10Gigabit Ethernet LAN port |
| USB | 2 x USB 3.0 Type A (Front) 2 x USB 2.0 Type A (rear) 4 x USB 3.2 Type A (rear) 1 x USB 3.2 Type C (rear) |
| Video Output |
1 x VGA |
| Serial Port |
2 x COM Port(s) (1 header; 1 rear) |
| DOM |
1 x SATA DOM power connector (Disk on Module) port |
| TPM |
1 x TPM Header |
| Chassis | |
| Form Factor | Rackmount |
| Expansion Slots | 7 x Low-Profile expansion slots |
| Dimension (DxWxH) | 695 x 433 x 87.6 (mm) / 27.36” x 17.04” x 3.44” |
| LEDs | 1 x Power LED 1 x HDD LED 1 x Alarm LED 2 x LAN Indicators |
| Ports | 2 x USB3.0 |
| SlideRail | Yes |
| Power Supply | 1300W Redundant |
| Supported OS | |
| Microsoft Windows | |
| Linux | |
| Virtual Machine | |
