เครื่องเซิร์ฟเวอร์ 3U PowerRACK B650D4U-3116, AMD EPYC, 4244P Raphael 6C/12T, 16Bays
- • Model: B650D4U-3116-1300R-S6C12T
- • CPU: 1 x CPU, AMD, AM5, EPYC, 4244P Raphael, 6C/12T, 3.8GHz, 32MB Cache, 65W
- • CPU Cooler: Active Sink
- • RAM: Option
- • SSD: Option
- • VGA: ASPEED AST2600/ AMD Radeon™ Graphics
- • RAID: RAID Controller, SAS, 9361-8i, 12Gb/s, SAS/SATA, 8port, 1GB
- • Drive: 16 x 2.5″/3.5″ Hot-swap, Rear 2 x 2.5″ Hot-swap
- • LAN: 2 x 1GbE
- • IPMI: 1 RJ45 Dedicated IPMI
- • Chassis: 3U Rackmount
- • PSU: 1300W Redundant
- • Warranty: 3-Year อะไหล่และค่าแรง, On-Shop Service
฿90,900.00
ติดต่อสอบถามเกี่ยวกับสินค้าทางไลน์ ก่อนชำระเงิน
Please contact us via LINE for product inquiries before making a payment.
PowerRACK
B650D4U-3116
เซิร์ฟเวอร์ที่ขับเคลื่อนด้วย AMD EPYC 4244P Raphael 6C/12T พร้อมพื้นที่จัดเก็บข้อมูล Hot-swap 16 Bays และ RAID Controller เพื่อความปลอดภัยของข้อมูล บริหารจัดการเครื่องจากระยะไกลได้ด้วย IPMI และยังมี Power Supply Redundant 1300W ช่วยให้ระบบทำงานได้อย่างต่อเนื่อง ตัวเครื่องรับประกัน 3 ปี อะไหล่และค่าแรง On-Shop Service
|
CPU |
|
|---|---|
| Standard CPU | CPU, AMD, AM5, EPYC, 4244P Raphael, 6C/12T, 3.8GHz, 32MB Cache, 65W |
| CPU Support |
Supports AMD Ryzen 7000 series Processors |
| CPU Cooler | 1 x Active Cooler |
| Memory | |
|
Standard Memory |
Option |
| Memory support |
Total Slots : 4Slots |
| Network / IPMI | |
| Integrated LAN |
2 x RJ45 10Gigabit Ethernet LAN ports with Intel® i210 LAN Ethernet Controller |
| IPMI |
1 x IPMI ASPEED AST2600 BMC |
|
Graphic |
|
| Controller |
ASPEED AST2600/ AMD Radeon™ Graphics |
|
Expansion Slots |
|
| PCI-Express (PCI-E) |
1 x PCIe 5.0 x16 slot |
| M.2 |
|
| Storage / Controller | |
| Standard Storage |
Option |
| Drive Bays |
Front 16 x 3.5″ Hot-swap HDDs (2.5″ HDD compatible) |
| Storage |
Internal 2 x 2.5″ HDDs |
| Storage Controller | RAID Controller, SAS, 9361-8i, 12Gb/s, SAS/SATA, 8port, 1GB |
| SATA |
4 x SATA (6Gbps) ports |
| Cable |
SFF 8643 to SFF 8643 |
| Input / Output | |
| LAN | 2 x RJ45 1Gigabit Ethernet LAN port |
| USB | 2 x USB 2.0 ports (front) 4 x USB 3.2 Type A (rear) |
| Video Output | 1 x VGA Port 1 x HDMI 1 x DisplayPort |
| Serial Port | 1 x COM Port |
| DOM | N/A |
| TPM | 1 x TPM Header |
| Chassis | |
| Form Factor |
3U |
| Expansion Slots |
7 x full-height & full-length expansion slots |
| Dimension (DxWxH) | 670 x 444 x 132mm (DxWxH) |
| Buttons |
1 x Power SW |
| LEDs | 1 x Power LED 1 x HDD LED 1 x Alarm LED 2 x LAN Indicators |
| Ports |
2 x USB2.0 |
| SlideRail | Yes |
|
Power Supply |
1300W Redundant |
|
Supported OS |
|
|
Microsoft Windows |
|
|
Linux |
|
|
Virtual Machine |
|
