ฮีตซิงค์ Dynatron L31, 1U Liquid Cooler , LGA 4677

  • ชุดน้ำระบบปิด Server Grade สำหรับ 1u Server
  • Intel Socket : LGA 4677
  • MAXIMUM POWER: 350W
  • สำหรับประกอบเครื่องชุดของทางร้านเท่านั้น

฿7,500.00

แจ้งกับทางร้านก่อนชำระเงิน เพื่อตรวจสอบสถานะสินค้า และค่าจัดส่ง

CPU Support

Intel

CPU Socket

Intel Socket LGA 4677

Weight

40 ± 10grams

Solution

1U Server

Water Pump

Stand-alone Water Pump with Powerful Flow Rate 1.7 Liter Per Minute

Radiator

Space-saving lightweight Radiator

Rated Voltage

12V

Speed

At Duty Cycle 0~20%: 2500 ± 10% RPM
At Duty Cycle 50%: 6700 ± 10% RPM
At Duty Cycle 100%: 12000 ±10% RPM

Power

At Duty Cycle 0~20%: 1.2 W
At Duty Cycle 50%: 3.0 W
At Duty Cycle 100%: 8.4 W

Air Flow

At Duty Cycle 0~20%: 5.175 CFM
At Duty Cycle 50%: 13.869 CFM
At Duty Cycle 100%: 24.840 CFM

Noise Level

At Duty Cycle 0~20%: 18.74 dBA
At Duty Cycle 50%: 40.15 dBA
At Duty Cycle 100%: 52.8 dBA

Air Pressure

At Duty Cycle 0~20%: 1.39 mm-H2O
At Duty Cycle 50%: 9.98 mm-H2O
At Duty Cycle 100%: 32.01 mm-H2O

Lead Wir Pin Out

Pin1- (-)
Pin2- (+)
Pin3- (Techometer/Signal output)
Pin4- (PWM)
