เซิร์ฟเวอร์ PowerRACK X13SCL-3116, Xeon E-2434 4C/8T, 16Bays
- • Model: X13SCLF-3116-1300R-S4C8T16G
- • CPU: Intel Xeon E-2434 (3.40GHz, 4C/8T, 12MB L3)
- • CPU Cooler: Active Sink
- • RAM: 16GB DDR5, ECC, UDIMM
- • SSD: 256GB SSD, SATA, 2.5″ (Non RAID)
- • VGA: Aspeed AST2500 BMC
- • RAID: RAID Controller, SAS, 9361-8i, 12Gb/s, SAS/SATA, 8port, 1GB
- • Drive: 16 x 2.5″/3.5″ Hot-swap, Rear 2 x 2.5″ Hot-swap
- • LAN: Dual port RJ45 (Intel i210 server adapter)
- • iKVM: Aspeed AST 2600 BMC chipset (hardware monitor, remote iKVM)
- • CHASSIS: 3U Rackmount
- • PSU: 1300W Redundant
- • Warranty: 2-Year อะไหล่และค่าแรง, On-Shop Service
฿97,850.00
ราคาล่าสุดวันที่ July 18, 2026
ติดต่อสอบถามเกี่ยวกับสินค้าทางไลน์ ก่อนชำระเงิน
Please contact us via LINE for product inquiries before making a payment.
PowerRACK
X13SCL-3116
เซิร์ฟเวอร์ที่มาพร้อม Intel Xeon E-2434 และหน่วยความจำ ECC DDR5 มอบการประมวลผลที่เสถียร และรองรับการทำงานหนักได้อย่างต่อเนื่อง มี Hot-swap 16 Bays พร้อม RAID Controller ช่วยเพิ่มความปลอดภัยและความยืดหยุ่นในการจัดเก็บข้อมูล บริหารจัดการเซิร์ฟเวอร์จากระยะไกลได้ด้วย Remote iKVM นอกจากนี้ยังมี Power Redundant 1300W พร้อมรับประกัน 2 ปี อะไหล่ค่าแรง บริการ On-Shop Service
| CPU | |
|---|---|
| Standard CPU | Intel Xeon E-2434 (3.40GHz, 4C/8T, 12MB L3) |
| CPU Support | Intel® Xeon® E-2400/Pentium®* Processor CPU TDP supports Up to 95W TDP *Pentium® G7400 and G7400T |
| CPU Cooler | Active Sink |
| Memory | |
| Standard Memory | 16GB DDR5, ECC UDIMM |
| Memory support | Total Slots : 2 DIMM slots Max Memory Size : 64GB Max. Capacity per DIMM : 8GB, 16GB, 32GB DIMM Type : DDR5 ECC-UDIMM Frequency : 4800/4400/4000 MT/s Up to 64GB of memory with speeds of up to 4800MT/s (1DPC) |
| Network / IPMI | |
| Integrated LAN | 2 x LAN with 1GbE with Intel® I210 |
| IPMI | 1 x ASPEED AST2600 BMC |
| Graphic | |
| Controller | Aspeed AST2500 BMC port |
| Expansion Slots | |
| PCI-Express (PCI-E) | 1 PCIe 5.0 x16, 1 PCIe 4.0 x4 SlimSAS, 2 PCIe 4.0×4 or 1 PCIe 4.0×4 & 4 SATA |
| M.2 | M.2 Interface: 1 PCIe 4.0 x4 Form Factor: 2280 Key: M-Key |
| Storage / Controller | |
| Standard Storage | 256GB SSD, SATA, 2.5″ (Non RAID) |
| Drive Bays | Front 16 x 3.5″ Hot-swap HDDs (2.5″ HDD compatible) Rear 2 x 2.5″ Hot-swap HDDs (option) |
| Storage | |
| Storage Controller | Intel® C262 |
| SATA | Intel® C262 controller for 6 SATA3 (6 Gbps) ports; RAID 0,1,5,10 |
| Cable | |
| Input / Output | |
| LAN | 2 x LAN with 1GbE with Intel® I210 1 x ASPEED AST2600 BMC |
| USB | 2 x USB 2.0 port(s) (2 rear) 2 x USB 3.0 port(s) (Front) 2 x USB 3.2 Gen1 port(s) (2 rear) |
| Video Output | 1 x VGA D-Sub Connector port(s) |
| Serial Port | 1 x COM Port(s) (1 rear) |
| UID | 1 x UID Button/LED |
| TPM | 1 TPM Header |
| Chassis | |
| Form Factor | 3U Rackmount |
| Expansion Slots | 7 x full-height & full-length expansion slots |
| Dimension (DxWxH) | 670 x 444 x 132mm (DxWxH) |
| Buttons | 1 x Power SW 1 x Reset SW |
| LEDs | 1 x Power LED 1 x HDD LED 1 x Alarm LED 2 x LAN Indicators |
| Ports | 2 x USB2.0 |
| SlideRail | Yes |
| Power Supply | 1300W Redundant |
| Supported OS | |
| Microsoft Windows | |
| Linux | |
| Virtual Machine | |
| Note | |
