KabyLake เซิร์ฟเวอร์ PowerRACK S5545AG2NR-4036 , Intel Pentium G4560 2C/4T, 36Bays
• Model: S5545AG2NR-4036-800-S2C4T
• CPU: 1 x Intel Pentium G4560 (2.5GHz, 2C/4T, 3MB L3)
• CPU Cooler: Active Sink
• RAM: Option
• SSD: Option
• VGA: Intel® HD Graphics 610 (CPU)
• RAID: Controller, SAS 9400-16i, 12Gb/s
• Drive: 24 x 2.5″/3.5″ Hot-Swap, 12 x 2.5″/3.5″ Hot-Swap (Rear)
• LAN: 2GLAN RJ45 (Intel® i210-AT, Intel® i219-LM (Intel AMT support)
• IPMI: –
• PSU: 800W Redundant 1+0 (call for option 1+1)
• CHASSIS: 4U Rackmount
• Warranty: 1Year อะไหล่และค่าแรง, On-Shop Service
฿80,500.00
ติดต่อสอบถามเกี่ยวกับสินค้าทางไลน์ ก่อนชำระเงิน
Please contact us via LINE for product inquiries before making a payment.
| CPU | |
|---|---|
| Standard CPU | 1 x Intel Pentium G4560 2Cores/4Threads 3.50GHz 3MB Cache 54W |
| CPU Support | Intel Core i7/i5/i3 Processors / 7th/6th Gen. |
| CPU Cooler | 1 x 1U Active Sink |
| Memory | |
| Standard Memory | Option |
| Memory support | Total Slots: 4 DIMM slots Max Memory Size : 64 GB ECC UDIMM Max. Capacity per DIMM : 4GB, 8GB, 16GB DIMM Type : DDR4 ECC-UDIMM Supports DDR4-2133/2400, DDR3L-1333/1600 MT/s |
| Network / IPMI | |
| Integrated LAN | 2 x RJ45 GLAN by Intel® i210-AT, Intel® i219-LM |
| IPMI | N/A |
| Graphic | |
| Controller | Intel® HD Graphics 610 (CPU) |
| Expansion Slots | |
| PCI-Express (PCI-E) | 1 x PCIe Gen.3 x1 slot 1 x PCIe Gen.3 x8 slot (w/ x4 link) 1 x PCIe Gen.3 x16 slot |
| M.2 | N/A |
| Storage / Controller | |
| Standard Storage | Option |
| Drive Bays | 24 x 2.5″/3.5″ Hot-Swap drive bays (Front) 12 x 2.5″/3.5″ Hot-Swap drive bays (Rear) |
| Storage Controller | Software RAID RAID support: 0,1,5,10,50,6,60 |
| SATA | 6 x SATA3 6Gb/s |
| Cable | 10 x SFF8643-SFF8643 |
| Input / Output | |
| LAN | 2 x RJ45 Gigabit Ethernet LAN ports |
| USB | 1 x Type-A (USB2.0) Front 2 x Type-A (USB2.0) Rear 4 x Type-A (USB3.0) Rear |
| Video Output | 2 x DisplayPort 1.2 1 x DVI-D |
| Serial Port | N/A |
| DOM | N/A |
| TPM | 2 x 8 pin header |
| Chassis | |
| Form Factor | 4U Rackmount |
| Expansion Slots | 7 x Slots Low-profile |
| Dimension (DxWxH) | 682 x 436 x 176mm (DxWxH) |
| Buttons | 1 x Power On/Off 1 x System Reset |
| LEDs | 1 x Power Status 1 x HDD Status 1 x LAN Activity |
| Ports | 2 x USB 2.0 |
| SlideRail | Yes |
| Power Supply | 800W Redundant 1+0 (call for option 1+1) |
| Supported OS | |
| Microsoft Windows |
Windows 8.1 Pro x64 |
| Linux |
CentOS 7.0×64 |
| Virtual Machine | N/A |
